Asbestos Free Woven Brake Lining Material For Sugar Mill Tractor
Crane Hoist,Non-asbestos Brake Lining
Description:
Non-asbestos Woven Brake Lining selects new-type abrasion resistant
and high temperature resistant non-asbestos yarns which contain
brass wires, viscose fiber, Glass fiber, Aramid fiber etc.
Our company has more than 25 years experience in manufacturing
Woven Brake Linings, which can bring mutual benefit and profits to
you and us.
Q: Can you offer sample to test?
A: Yes, we can offer free sample, customer only need to pay the
shipping charge.
Q: Are you trading company or manufacturer?
A: We are a big manufacturer.
Q: Can you make different colors?
A: Yes. We can customize 3 kinds of colors.
Q: What's your acceptable payment term?
A: Our usual payment term is T/T.
Q: Can I visit your factory?
A: You are warmly welcomed to visit our factory, and we offer free
hotel and free car service.
Materials:Asbestos Free Woven Brake Lining Material For Sugar Mill Tractor
Crane Hoist,Non-asbestos Brake Lining
Brass wire, glass fiber, viscose fiber, resin and friction
materials, etc. Its coefficient of friction has a high capacity to absorb loads by
impact and excellent resistance to mechanical stress.
Characteristics:
1. Good flexibility,
2. Excellent oil resistance and water resistance,
3. High tenacity, shock resisting, heat resisting,
4. Good duality and anastomosis, agile brake.
Specifications:Asbestos Free Woven Brake Lining Material For Sugar Mill Tractor
Crane Hoist,Non-asbestos Brake Lining
| Temperature | Coefficient of friction(μ) | Wear rate(v)(cm³/N.m) |
| 100℃ | 0.35~0.65 | ≤0.7 x 10-7 |
| 150℃ | 0.35~0.65 | ≤1.1 x 10-7 |
| 200℃ | 0.30~0.60 | ≤1.5 x 10-7 |
| 250℃ | 0.25~0.60 | ≤2.5 x 10-7 |
Quick Detail:Asbestos Free Woven Brake Lining Material For Sugar Mill Tractor
Crane Hoist,Non-asbestos Brake Lining
Model: BXS-M Non-asbestos Woven Brake Lining
Material: Viscose fiber, Aramid fiber, glass fiber, 2 brass wires,
Melamine resin.
Working Conditions: 250℃,Static Pressure: 4.0Mpa
Applied field: It is widely used for braking deceleration and
transmitting power of big power machineries.
Specification: T(5~30)x W(≤500)mm ; Available Length: 10m,15m,20m
Color: Yellow
Competitive Advantage:Asbestos Free Woven Brake Lining Material For Sugar Mill Tractor
Crane Hoist,Non-asbestos Brake Lining
We produce non-asbestos yarns by ourself and weave yarns to
non-asbestos brake lining. We can control the whole quality from
raw materials to finished products. You don't need feel worry about
the quality. I can say that we have the best cost performance in
Chinese market.
We adopt Japanese Technology. All yarns are woven by advanced
Japanese loom machinery & equipment then impregnate into specially
formulated polymer resin, through high temperature, low temperature
etc. processing workmanship.
